Water Pump Fits 85-95 Toyota 2.4L SOHC 8v / 22R, 22RE, 22REC,
22RTEC #170-1640 / AW9141
Car Application:
88-95 Toyota 4 Runner L4-2366cc 2.4L F/I Vin 22RE 22REC |
85-88 Toyota 4 Runner L4-2366cc 2.4L F/I TURBO Vin 22RTEC |
1985 Toyota Celica L4-2366cc 2.4L F/I Vin 22REC |
85-95 Toyota Pickup L4-2366cc 2.4L F/I Vin 22RE |
85-95 Toyota Pickup L4-2366cc 2.4L F/I Vin 22 REC |
85-95 Toyota Pickup L4-2366cc 2.4L 2 BBL Vin 22R |
85-95 Toyota Pickup L4-2366cc 2.4L F/I TURBO Vin 22RTEC |
1987 Toyota Pickup (CAN) L4-2366cc 2.4L Diesel Vin L |
1988 Toyota Van Wagon L4-2366cc 2.4L F/I Vin R |
What is a water pump
The water pump is the heart of the cooling system and is
responsible for circulating coolant, consisting of housing (aluminum diecast, cast iron, aluminum gravity etc),
flange(forged steel, sintered iron etc), impeller (pressed steel,
cast iron, synthetic resin etc), water pump bearing and mechanical
seal kit.
Water pumps’ material is depending on performance level, quality as
well as customer requirements and working conditions.
Water pump circulates coolant between the engine and radiator to
keep the engine from overheating. Inside the water pump is a metal
or plastic impeller with blades that push the water through the
pump. The impeller is mounted on a shaft that is supported by the
pump housing with a bearing and seal assembly. The cooling liquid
absorbs the heat from the engine block and cylinder head and
releases it into the ambient air through the radiator.
The water pump is usually driven by V-belts or poly-rib belts
depending on their installation location in the engine. It’s
mounted on the engine block from the outside and can be replaced
without having to open the engine itself.
Water Pump critical quality
When water pumps fail, the engine overheats, which can result in
serious engine damage. Water pumps are typical wear parts, which
must sometimes be replaced several times during the service life of
the engine.
Water pumps typically fail one of two ways: the shaft seal starts
to leak, or the impeller inside breaks, comes loose or the blades
erode and wear down (which is more of a problem with pumps that
have plastic impellers).
Product description
Maojia Industry’s water pumps are recognized in the aftermarket for
their durability and superior quality. All our water pumps are
constructed with premium alloy materials and a 100% functional test
of seals and bearings along with a 100% leakage test for both the
casting and assembled water pump. We are committed to supplying the
highest quality new and OE performance water pumps in the global
automotive market.
Maojia Industry’s water pumps advantages
1. Wide product range for global aftermarket.
2. Advanced Test-bed for the Comprehensive Cooling Performance of
Combustion Engine and Reliability of Water Pump, automatically
collecting data to test such performance parameters as rotation
speed, delivery lift, flow rate, power capacity and efficiency.
3. 100% Quality controled by the following advanced test machine.
Bearing Vibration Tester, Bearing Clearance Tester, Water Seal Leak
Detector, all above testing machines are maintained and calibrated
regularly; All operators have attended professional training and
operate testers under standard-operating procedures.
